KRATKI LUCY 12 kW Wood-Fired Water Fireplace Ø 200
3.285,15 €
VAT included
Available
Ref. LUCY/PW/12/W
We will confirm delivery times, transport and installation with no obligation.
Description
MAXIMUM ENERGY EFFICIENCY
The body and front of the insert are heat-resistant thanks to high-quality steel used in production.
A special water system allows a large amount of smoke heat to be transferred to the heating system, resulting in high energy efficiency.
Overheating protection via an integrated coil tube - 1/2" inlet/outlet connector.
Efficient combustion process and temperature maintenance for longer-lasting warmth thanks to TERMOTEC lining of the combustion chamber – a heat accumulator material that increases the temperature in the combustion chamber.
More eco-friendly combustion thanks to the double deflector system which extends the path of exhaust gases.
Air supply only from outside via an external biult-in air inlet of 125 mm. Air regulation with a single regulator prevents improper use.
Triple ventilation system for the combustion chamber: primary air – secondary air supplied under the grate through holes in a rear wall. Additionally, a clean glass system (air curtain) has been designed.
HIGHEST LEVEL OF SAFETY
Perfect tightness thanks to solid welds made with noble gas shielding.
All steel parts are laser-cut and bent in CNC bending machines.
The insert front is equipped with heat-resistant ceramic that withstands temperatures up to 660°C.
EASY TO USE
Movable grate and ash tray allow cleaning of the plate.
The special perforated design of the handle protects against excessive heating, contributing to high comfort when using the fireplace.
Reduction of soot deposition thanks to a pure glass system (air curtain).
Can be used in various mounting conditions thanks to adjustable feet and mobile flue outlet with 360º adjustment.
MODERN DESIGN
Decorative heat-resistant glass that withstands temperatures up to 660°C. Gives the fireplace a modern and elegant look, visually widening the insert front.
An elegant and comfortable handle.
Specifications
- Material
- Acero
- Alto (cm)
- 138.4
- Ancho (cm)
- 67.6
- Profundidad (cm)
- 40.7
- Peso (kg)
- 215
- Potencia nominal (kW)
- 12
- Certificados
- KRATKI PRO, Ecodiseño, Destinado a recuperación, BImSchV 2
- Tipo de combustible
- Madera caducifolaria sazonada (humedad ?20%)
- EAN
- 5901350036426
- Equipo
- Cargando la cámara de combustión, Ceniza, Toma de aire, Vidrio decorativo
- Rango de potencia calorífica (kW)
- 5.0 - 15.0
- Eficiencia térmica (%)
- 82
- Temperatura de los gases de combustión (oC)
- 204
- Longitud máxima de la palanquilla (cm)
- 50
- CIERRE
- No
- Apertura de puerta
- Izquierda
- diámetro de la salida de gases de combustión
- 200
- Clase energética
- A+
- EEI
- 108
- Eficiencia energética estacional (%)
- 72
- Potencia calorífica para la calefacción de espacios (kW)
- 5
- La emisión de CO (al 13% de O2) ? expresada en %
- 0.093
- Emisión de CO (mg/m3)
- 1173
- Emisión de polen (mg/m3)
- 24
- Emisión de NOx (mg/m3)
- 127
- Emisión de OGC (mg/m3)
- 48
- Área activa mínima requerida de las rejillas de entrada (cm2)
- 150
- Campo activo mínimo requerido de las rejillas de salida (cm2)
- 300
- Potencia media del agua (kW)
- 7
- Presión máxima de trabajo (bar)
- 2
- Capacidad de agua (l)
- 35
